OUTPUT (±10%)………………………5 g/hr
FLOW RATE (max)……………………6 scfh (2.8 lpm)
CONCENTRATION……………………2.0% – 2.5% WEIGHT
POWER REQUIREMENTS:
DOMESTIC MODEL………230 VAC, 50 Hz, 1Ø, 2.5 Amps
HEAT REJECTION……………………1962 BTU/hr (577 WATTS)
WEIGHT……………………………… 50 lb (23 kg)
LOCATION REQUIREMENTS*
MOUNTING…………………WALL MOUNT IN A CLEAN, PROTECTED AREA USING SUPPLIED BRACKETS.
AMBIENT TEMP……………40°F – 100°F (5°C – 38°C)
VENTILATION………………CLOSED ROOM REQUIRES 6 AIR CHANGES PER HOUR. (MIN)
